Post by john88z on Dec 23, 2009 20:38:21 GMT
A quick tutorial on how to scale brushes for use in 3D skyboxes. This tutorial assumes you have prior knowlege on how to create the 3D skybox. First off build the structure you want scaled. For this tut, I will be using this building: Next select everything, hit ctrl+m to open the Transformations window. Set the mode to scale, and use the value ".0625"* for the x, y, and z values. Your screen should look something like this: Click 'OK' and your building will now be scaled accordingly. You can now add this into your 3d skybox, along with scaled props and an env_cubemap. The finished product: *The scale value, .0625 relates to the value set on the sky_camera. If you set the scale value on the sky_camera to anything else, divide it by a hundred to find out what value to use when scaling your building.
|
|
|
Post by Zeph on Dec 23, 2009 21:22:51 GMT
Nice, that makes things easier to build them to scale then shrink them.
|
|
|
Post by motanum on Dec 23, 2009 22:48:14 GMT
Nice! Just what I was looking for!
Also, Can you scale this way some static world models?
|
|
|
Post by john88z on Dec 24, 2009 1:10:45 GMT
Like props? No, only brush based geometry can be scaled.
|
|
|
Post by dafatcat on Dec 24, 2009 4:47:51 GMT
Shouldn't you use 1/16 (0.0625) scale? I think skybox models are 1/16 scale.
|
|
|
Post by Zeph on Dec 24, 2009 10:52:04 GMT
(i was a little bit concerned about that, i thought it was a smaller fraction too)
|
|
|
Post by john88z on Dec 26, 2009 2:11:19 GMT
Ah yes it would be. Thank you for pointing that out.
|
|
|
Post by gingkao00 on Nov 22, 2010 4:02:51 GMT
cool even tho im new and dont know what to do or how to play this game or the point of it
|
|
|
Post by Zeph on Nov 22, 2010 11:07:01 GMT
It's not a game, it's a map editor / creator, for creating custom maps for the games.
|
|
